Fansız Endüstriyel PC

DC-1200

Onboard Intel® Pentium® N4200 Processor

  • Onboard Intel® Pentium® N4200 Processor
  • Supports Triple Independent Display
  • Supports CMI Interface for I/O Expandability
  • Supports PoE+ and Power Ignition Function (with optional CFM modules)
  • 1x 2.5” SATA Drive Bay, 1x mSATA Socket
  • 2x Full Size Mini-PCIe Socket, 2x SIM Card Socket
  • Compact Size (185 x 131 x 56.5 mm)
  • Wide Operating Temperature -40°C to 70°C
  • E-Mark (E13, No. 10R-0515075), LVD EN62368-1
Destekleyen İşlemciler
  • DC-1200
  • DC-1200
  • DC-1200
  • DC-1200
  • DC-1200
  • DC-1200
  • DC-1200
Fansız Endüstriyel PC

DC-1200

Based on Intel® Pentium® N4200 quad-core processor, the DC-1200 is a fanless embedded computer oering an incredible size-performance ratio for the most challenging environments. Despite its compact size, the DC-1200 incorporates extensive connectivities including serial ports, USB 3.0, GbE LAN, full-size Mini-PCIe slot, dual SIM sockets, DVI-D, and DisplayPort. The system also provides 2.5″ SATA drive bay and mSATA socket for extensive storage requirements. Furthermore, it is much easier to utilize Cincoze’ ready-to-use CMI& CFM modules for extension of digital I/O, serial ports, power ignition sensing, Power over Ethernet (PoE) even the third output of video for a variety of applications. Featuring with rigorous industrial protections, wide temperature range, and wide range DC power input, the DC-1200 oers a powerful, expandable computing platform to ensure long-lasting performance and reduce maintenance costs

Available Models
Model No. Product Description
DC-1200-N42-R10 Intel® Pentium® Processor N4200 Compact Size Fanless Computer
Package Checklist

√ DC-1200 Compact Size Fanless Embedded Computer x1

√ Thermal Pad (for CPU Thermal Block) x 1

√ Screw Pack x1

√ Wall Mounting Kit x1

√ Power Terminal Block Connector x1

√ Remote Power On/Off Terminal Block Connector x1

√ DIN Rail Mounting Kit x1

Optional Modules & Accessories
Model No. Description
CMI-DVI01/UB1107 CMI Module with 1x DVI-D Connector for DC-1200,1x Universal Bracket with 1x DVI-D Cutout for DC-1200
CMI-VGA01/UB1116 CMI Module with 1x VGA Port for DC-1200, 1x Universal Bracket with 1x VGA Cutout for DC-1200
CMI-HD02/UB1108 CMI Module with 1x HDMI Port for DC-1200,1x Universal Bracket with 1x HDMI Cutout for DC-1200
CMI-COM03/UB1103 CMI Module with 2x RS232/422/485 (Support 5V/12V) for DC-1200,1x Universal Bracket with 2x DB9 Cutout for DC-1200
CMI-DIO03/UB1115 CMI Module with 8x Optical Isolated DIO (4 in/4 out) for DC-1200,1x Universal Bracket with DIO Cutout for DC-1200
CFM-IGN02 CFM Module with Power Ignition Sensing Control Function, Select 12V/24V
CFM-PoE02 CFM Module with PoE Control Function, Individual Port 25.5W
MEC-COM-M212-TDB9/UB1103 Mini-PCIe Module with 2x COM Ports,1x Universal Bracket with 2x DB9 Cutout for DC-1200
MEC-LAN-M102-15/UB1111 Mini-PCIe Module with 2x LAN Ports / 1x Universal Bracket with 2x RJ45 Cutout for DC-1200 Front Bezel
MEC-LAN-M102-15/UB1129 Mini-PCIe Module with 2x LAN Ports / 1x Universal Bracket with 2x RJ45 Cutout for DC-1200 Rear Bezel
SIDE03 Side Mount Kit for DC-1200 Series, with KMRH-K175 for DIN-Rail option
GST60A12-CIN1 Adapter AC/DC 12V 5A 60W, GST60A12-CIN1, wide temp(-30°C ~ +70°C), level VI
GST120A24-CIN Adapter AC/DC 24V 5A 120W, GST120A24-CIN, wide temp(-30°C ~ +70°C), level VI
SL2-SL3 US 2 heads power cord, US B type to IEC C13, SVT 18AWG/3C Black 1.8M SL-2+SL-3
SL6-SL3 EU 2 heads power cord, EU G type to IEC C13, H05VV-F 0.75mm2/3G Black 1.8M SL-6+SL-3
QP026-SL3 UK 2 heads power cord, UK I type to IEC C13, H05VV-F 0.75mm2/3G Black 1.8M QP026+SL-3

Ürün Özellikleri

Model Name DC-1200
Processor System CPU Onboard Intel® Pentium® N4200 Quad Core Processor, up to 2.50 GHz
BIOS AMI BIOS, 8MB SPI Flash ROM built on board
Memory Technology DDR3L 1333/1600/1866 MHz (un-buffered and non-ECC)
Max. Capacity 8 GB
Socket 1x 204-Pin SO-DIMM
Display Integrated Graphics Integrated Intel® HD Graphics 505 (Pentium® N4200)
Triple Display Supported Yes (DVI-D, DisplayPort and one output from optional CMI module)
Audio Codec Realtek ALC888-GR
I/O Ports DVI-D 1 (1920 x 1080 @60Hz)
DP 1 (4096 x 2160 @ 60Hz, According to CPU Specifications)
* Verified maximum resolution: 3840×2160.
GbE LAN 2 (RJ45, Intel® I210 Supports WoL, Teaming, Jumbo Frame & PXE)
USB 3.2 Gen1 4
COM Port 2 (DB9, RS-232/422/485 with Auto Flow Control (Supports 5V/12V))
Line-out 1
Mic-in 1
ATX Power On/Off Button 1
AT/ATX Mode Switch 1
Clear CMOS Switch 1
Remote Power On/Off Connector 1
Ignition DIP Switch 1 (12V/24V, need to work with CFM module)
Storage 2.5” HDD/SSD Drive Bay 1 (SATA 3.0)
mSATA 1 (SATA 3.0, Shared by Mini-PCIe Socket)
Expansion Mini-PCIe Socket 2 (Full-size)
SIM Socket 2 (for Signal Redundancy)
Control Function Module (CFM) Interface 2
Combined Multiple I/O (CMI) Interface 2
Antenna Holes 2
Other Functions Watchdog Timer Software Programmable Supports 256 Levels System Reset
Supports Instant Reboot Technology 0.2 sec
Power
Requirement
Power Type AT / ATX
Power Supply Voltage 9~48VDC
Power Connector 1x 3-pin Terminal Block
Power Adaptor Power Adapter AC/DC 12V/5A 60W or 24V/5A 120W (Optional)
Physical Dimension (WxDxH) 185 x 131 x 56.5 mm
Weight 1.42kg
Construction Extruded Aluminum with Heavy Duty Metal
Mounting Wall / VESA / Din Rail (Optional: Side + Din Rail Mounting Kit)
Unibody Chassis Yes
Fanless Design Yes
Jumper-less Design Yes
Cable-less Design Yes
Protection Reverse Power Input Protection Yes
Over Voltage Protection Protection Range: 51~58V
Protection Type: shut down operating voltage, re-power on at the preset level to recover
Over Current Protection 15A
Operating System Windows Windows® 10
Linux Supports by project
Environment Operating Temperature -40°C to 70°C
* With extended temperature peripherals; Ambient with air flow
* According to IEC60068-2-1, IEC60068-2-2, IEC60068-2-14
Storage Temperature -40°C to 85°C
Relative Humidity 95%RH @ 70°C (non-Condensing)
Shock Operating, 50 Grms, Half-sine 11 ms Duration
* w/ SSD, according to IEC60068-2-27
Vibration Operating, 5 Grms, 5-500 Hz, 3 Axes
* w/ SSD, according to IEC60068-2-64
MTBF 479,119Hours
EMC • CE, UKCA, FCC, ICES-003 Class A
• E-mark
EMI • CISPR 32 Conducted & Radiated: Class A
• EN/BS EN 55032 Conducted & Radiated: Class A
• EN/BS EN IEC 61000-3-2 Harmonic current emissions: Class A
• EN/BS EN61000-3-3 Voltage fluctuations & flicker
• FCC 47 CFR Part 15B, ICES-003 Conducted & Radiated: Class A
EMS • EN/IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV
• EN/IEC 61000-4-3 RS: 80 MHz to 1000 MHz: 3 V/m
• EN/IEC 61000-4-4 EFT: AC Power: 1 kV; DC Power: 0.5 kV; Signal: 0.5 kV
• EN/IEC 61000-4-5 Surges: AC Power: 2 kV; Signal: 1 kV
• EN/IEC 61000-4-6 CS: 3V
• EN/IEC 61000-4-8 PFMF: 50 Hz, 1A/m
• EN/IEC 61000-4-11 Voltage Dips & Voltage Interruptions: 0.5 cycles at 50 Hz
Safety LVD IEC/EN 62368-1
