Edge AI Jetson PC

IBOX-600 Series

NVIDIA® Jetson Orin NX/Nano Fanless Edge AI Computer

  • ARM® Cortex®-A78AE 8-core Processor
  • 1024 NVIDIA® CUDA® Cores, 32 Tensor Cores
  • 3 x M.2 Slots for Wi-Fi / WWAN / SSD Expansion
  • 1 x CAN FD for Vehicle Connection
  • Selectable for RJ-45 / M12X Ethernet Connetors
  • JetPack™ SDK Includes Development Tools
  • Power Input 9~60VDC with Smart Power Management
  • Operating Temperature -25°C ~ 70°C
  • Patented Backup Battery Kit (UPS) for Emergencies
Edge AI Jetson PC

IBOX-600 Series

Elevate your next-gen AI application with IBOX-600, an Fanless AI computer powered by NVIDIA Jetson platform. Driven by ARM 8-core Cortex-A78E processor, 1024 NVIDIA CUDA cores, and 32 Tensor cores, IBOX-600 is perfect for intelligent transportation infrastructure and advanced driver assistance systems, enabling high-performance Edge AI applications.

IBOX-600 features versatile expansion slots and 2 high-speed Ethernet ports, supporting a wide input voltage range. These features come in one compact chassis with fanless thermal design, allowing effortless installation in limited space.

ORDERING INFORMATION
Model Number:

IBOX-600-xxxx-yyyyy (xxxx= = ETH w/ RJ-45, xxxx=M12X= ETH w/ M12 X-coded)
yyyyy=ONX16=Jetson Orin NX 16GB / yyyyy=ONX8=Jetson Orin NX 8GB
yyyyy=ON8=Jetson Orin Nano 8GB / yyyyy=ON4=Jetson Orin Nano 4GB
*Jetson Orin SoM Lifecycle is available through January 2030.

Description:

NVIDIA® Jetson Orin NX/Nano SoM w/ 2x LAN/ 1x HDMI® / 1x CAN bus/ DC 9-60V/ Intelligent Computer

OPTIONAL ACCESSORIES
Wi-Fi:

M.2 Wi-Fi Module

WWAN Modem

M.2 WWAN Modem

GPS

mPCIe GPS Module

Mounting kit

DIN Rail / VESA Kit

Ürün Özellikleri
