Edge AI Jetson PC

IBOX-650P-IP66

NVIDIA® Jetson AGX Orin™ Edge AI Fanless Computer

  • NVIDIA® Jetson AGX Orin™ SoM with 2048 CUDA Cores
  • IP66 Design (Waterproof and Dustproof) for Harsh Environment
  • 1 x 10 GbE, 2 GbE with PoE via Phoenix Contact® M12 IP67 Connectors
  • 2 x CAN FD
  • 2 x RS-232/422/485*, 4 x DI/4 x DO*
  • Supporting 4 x GMSL-2 Cameras (via FAKRA Connectors)
  • 9 ~ 60VDC Input with Built-in Smart Ignition Power Management
  • -25 ~ 70°C Operating with Fanless Design
  • Patented Design of Emergency Backup Battery*
Edge AI Jetson PC

IBOX-650P-IP66

Module:

  • NVIDIA® Jetson AGX Orin™ 64GB – 275 TOPS
    (2048 CUDA® cores GPU + 12-core Arm Cortex-A78AE CPU + 64 GB LPDDR5)
  • NVIDIA® Jetson AGX Orin™ 32GB – 200 TOPS
    (1792 CUDA® cores GPU + 8-core Arm Cortex-A78AE CPU + 32 GB LPDDR5)

Network:

Marvell® Industrial 10GbE, Intel® Industrial 2.5GbE

Security:

Security Boot, Arm TrustZone

ORDERING INFORMATION
  • IBOX-650P-IP66-JAO64|NVIDIA® Jetson AGX Orin™ 64GB / GMSL / IP66 / Model M12X
  • IBOX-650P-IP66-JAO32|NVIDIA® Jetson AGX Orin™ 32GB / GMSL / IP66 / Model M12X
  • IBOX-650P-IP66-JAO32-LE|NVIDIA® Jetson AGX Orin™ 32GB / IP66 / Model M12X
Optional Accessory
Storage:

M.2 2280 NVMe SSD 480GB / 960GB

Wi-Fi:

M.2 2230 Wi-Fi Module

GNSS:

mPCIe GPS Module
