LTE Modüller

LTE-5G

LTE/5G Data Card

These data cards lay the foundation for businesses worldwide to future-proof IoT, enterprise applications and video. They leverage 5G and Gigabit LTE benefits immediately.

  • 5G sub-6 FDD and TDD, SA and NSA operations
  • 5G core network Opt. 3a/3x and Opt. 2
  • 4G (FN990A40): 7xCA up to 20 layers DL/ 2xCA UL, 256-QAM DL/UL
  • 4G (FN990A28): 5xCA up to 19 layers DL/2xCA UL, 256-QAM DL/UL
  • 3G: HSPA+ Rel 8 (42 DL/11 UL Mbps)
LTE Modüller

LTE-5G

Certifications:

Anatel*, FCC, IC, RED, NCC, JATE/TELEC, KC, CCC*, RCM, GCF, PTCRB, AT&T, FirstNet, KDDI, KT*, Telstra, T-Mobile US, VzW, Various MNOs

Dimensions:

  • 30 x 52 x 2.25 mm

Operating Temperature Range:

  • -40° C to +85° C

LTE/5G Sub-6 Output Power:

  • 23 dBm (Power Class 3)
  • 26 dBm (Power Class 2) in B41/n41
  • 29 dBm (Power class 1.5) on n41, n77, n78 and n79: FN990A28-HP and FN990A40-HP only

Supply Voltage:

  • Nominal: 3.3 V dc
Sipariş Bilgileri

LTE-5G

Ürün Özellikleri
