Endüstriyel Mobil PC

VBOX-3200-IP65 (EOL)

AMD G-T56N Dual Core APU with Radeon HD 6320 IP65 On-Board Computer

ÜRÜN ÖZELLİKLERİ

  • AMD G-T56N Dual Core APU with Radeon HD 6320
  • Wireless Support LTE
  • 3.5G
  • WLAN
  • GPS
  • GSM/GPRS
  • Bluetooth
  • 9V – 32V DC Power Input
  • Smarter Vehicle Power Ignition for Variety Vehicle
  • 4 x DI / 2 x DO with Relay 12V / 80mA
  • IP65 Level for Water and Dust Proof
  • e-Mark Certificate

Ürün Özellikleri

CPU AMD G-T56N Dual Core 1.65GHz

AMD G-T40E Dual Core 1.0GHZ (Optional)

AMD G-T48E Dual Core 1.4GHz (Optional)

Memory 2 x DDR3 1333MHz SO-DIMM up to 8GB
Chipset AMD A50M Controller Hub
LAN Chipset 2 x Realtek RTL8111E Gb/s Ethernet Onboard, Support PXE and Wake On Lan
Audio Realtek ALC662 HD Codec Onboard
Watchdog 1 ~ 255 Level Reset
POWER REUQIREMENT
Power Input 9V -32V DC Power Input
Power Protection Automatics Recovery Short Circuit Protection
Power Management Vehicle Power Ignition for Variety Vehicle
PPower Off Control Power off Delay Time Setting by Software, Default is 5 Mins
Backup Battery Internal Battery Kit for 10 Mins Operating (Optional)

Patent No. : M447854 – Build-in Battery

GRAPHICS
Graphics AMD G-T56N Radeon HD 6320

UVD3 Hardware Video Decoder – MPEG2, MPEG4, H.264, VC-1, WMV

Resolution Up to 2560 x 1600 @ 85Hz
I/O
Serial Port 2 x RS-232 with RS-422/485 (Auto Direction Control))
USB Port 4 x USB 2.0 ports on Front I/O
LAN 2 x M12 Pports for GbE
Video Port 1 x DVI-I
DIO Port 4 in and 2 out with Relay 12V / 80mA
Audio 1 x Line-out, 1 x Mic-in and 1 x Line-in
SIM Card Socket 2 x SIM Card sockets supported onboard with eject
MECHANICAL & ENVIRONMENTAL
Dimension (LxWxH) 250 x 150 x 55 mm
Weight 1780g (bare-bone)
Relative Humidity 5 ~ 95% (non-condensing)
Operating Temp. -40 ~ 70°C(SSD), ambient w/ air
Storage Temp. -40 ~ 80°C
Certifications CE, FCC Class A, EN50155, EN50121, eMark Compliance
IP Rating IP65
Patent No. (Taiwan) M447854, M448011
