VDB-810DR

Embedded u-blox NEO-M8U GPS with Untethered Dead Reckoning UDR & G-Sensor Mini PCIe Card

  • u-blox 72-channel NEO-M8U UDR module including
  • 3D inertial sensors engine
  • GNSS data is available in NMEA, UBX & RTCM protocols
  • Max. 20Hz Navigation update rate
  • Position accuracy 2m CEP
  • Temperature range: -40 to +85°C
  • Mini PCIe Signal Type USB2.0
  • Standard Full/Half-size Mini PCIe Card connects to computer easily
GPS / GNSS Modüller

VDB-810DR

Chipset : NEO-M8U

Receiver Type : GPS L1C/A, SBAS L1C/A, QZSS L1C/A, QZSS L1-SAIF, GLONASS L1OF, BeiDou B1I, Galileo E1B/C

Channels : Supports 72 Channels

GNSS Center :BeiDou : 1561.098 MHz, GPS : 1575.42 MHz

Frequency : Glonass : 1602.5625

Sipariş Bilgileri

VDB-810DR
